詳細信息
可選設備機型 | SX-DH6 | SX-DH8 | |
適用冷媒 Applicable refrigerants | R170、R23、R23、R13、R508b、R744等高壓低溫系列冷媒 R170, R23, R23, R13, R508b and other high pressure and low temperature series of refrigerant | ||
加注量范圍 Filling quantity range（g） | 3-299 | 10-1999（定制） | |
加注速度 Charging speed (g/s) | 3-10 | 30-60 | |
充注壓力 Charging pressure | 2.0-3.0MPa | 4.0-6.5MPa | |
充注精度 Charging precision | 100g以內≤±1g 100g以上≤±1% ≤ ± 1 g 100g Up ≤ ± 1% within 100 g 1% | ||
計量方式 Measurement methods | VIS系列德國原裝流量計（可選裝RHEONIK質量流量計） VIS series Germany original flowmeter, Rheonik mass flowmeter optional
| ||
流量分辨率 Resolution |
0.1g |
0.1g | |
本機真空速率 Vacuum speed | 8L/S | 12L/S | |
本機真空度 The machine vacuum | ≤3Pa-8Pa | ≤3Pa-8Pa | |
本機真空度 The machine vacuum | 3Pa-9999Pa | 3Pa-9999Pa | |
觸摸屏、控制器、模塊 PLC、HMI、Admodule | 歐姆龍/西門子 Omron/Siemens7" | ||
增壓泵站 Booster pump station | 內置增壓站 Built-in booster station | ||
電源及額定功率 Voltage & Power | AC380V 50HZ or AC220 50HZ 60HZ /1.0KW | AC380V 50HZ or AC22050HZ 60HZ /1.5KW | |
充注槍及接口 Injector and quick connector | 1/4"(3/8") | ||
條形碼閱讀功能 Barcode reading function | 選裝 Optional
| ||
通信接口 Communication interface | RS485/RS232/以太網 | ||
適用產品類別（參照） Apply product category | 熱管、太陽花、散熱板、特殊空調、小型機組等特殊場合，可根據客戶要求定制產品。 Heat pipe, sunflower, heat plate, special air conditioning, small unit and other special occasions, can be customized according to customer requirements | ||
體積/重量 Volume/Weight | L850xW950xH1250mm/235KG | L850xW950xH1250mm/265KG | |
特殊要求 special requirements | 特殊配置與技術要求，另行約定 Special configuration and technical requirements,in addition to discuss | ||
